2019 Husqvarna TC 85 17-14 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2019 Husqvarna TC 85 17-14.

Basic Specs

Year2019
MakeHusqvarna
ModelHusqvarna TC 85 17-14
Cost

Engine

Displacement84.90 ccm (5.18 cubic inches)
Type
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke39.5 x 40.0 mm (1.6 x 1.6 inches)
Valves/Cylinder
FuelingCarburettor
IgnitionMEDJ digital
Exhaust
LubricationMixture oil lubrication
Cooling

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet, multi-disc clutch, Formula hydraulics
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity5.00 litres (1.32 gallons)
Emissions

Chassis

Frame TypeChrome-molybdenum steel central-tube frame
Rake
Trail
Front SuspensionWP upside-down 43  mm
Front Travel280 mm (11.0 inches)
Rear SuspensionWP PDS shock absorber
Rear Travel305 mm (12.0 inches)
Seat
Seat Height850 mm (33.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance252 mm (9.9 inches)
Wheelbase1,290 mm (50.8 inches)
Dry Weight67.0 kg (147.7 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre80/100-17
Rear Tire/Tyre120/90-14
Front BrakesSingle disc. Formula
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc. Formula
Rear Brake Diameter210 mm (8.3 inches)
Wheels

Comments

It appears you're interested in specifications for the Husqvarna TC 85 17-14. This Cross / motocross model is powered by a Single cylinder, two-stroke engine with 84.90 ccm (5.18 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor allowing this machine to produce its horsepower and torque. According to our records engine heat of the Husqvarna TC 85 17-14 is moderated by . You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 80/100-17 and the rear is 120/90-14 . The entire package is supported by the frame, Chrome-molybdenum steel central-tube frame. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Formula front brakes and Single disc. Formula rear brakes. The Husqvarna TC 85 17-14 was launched in 2019, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
