These are the known mechanical and performance specifications for your 2019 Husqvarna TC 85 17-14.
Basic Specs
Engine
Displacement84.90 ccm (5.18 cubic inches)
Type
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke39.5 x 40.0 mm (1.6 x 1.6 inches)
Valves/Cylinder
FuelingCarburettor
IgnitionMEDJ digital
Exhaust
LubricationMixture oil lubrication
Cooling
Drivetrain
Gearbox6-speed
Final DriveChain
ClutchWet, multi-disc clutch, Formula hydraulics
Driveline
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity5.00 litres (1.32 gallons)
Emissions
Chassis
Frame TypeChrome-molybdenum steel central-tube frame
Rake
Trail
Front SuspensionWP upside-down 43 mm
Front Travel280 mm (11.0 inches)
Rear SuspensionWP PDS shock absorber
Rear Travel305 mm (12.0 inches)
Seat
Seat Height850 mm (33.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance252 mm (9.9 inches)
Wheelbase1,290 mm (50.8 inches)
Dry Weight67.0 kg (147.7 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre80/100-17
Rear Tire/Tyre120/90-14
Front BrakesSingle disc. Formula
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc. Formula
Rear Brake Diameter210 mm (8.3 inches)
Wheels
