2020 AJP PR5 250 Extrem Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 AJP PR5 250 Extrem.

Basic Specs

Year2020
MakeAJP
ModelAJP PR5 250 Extrem
Cost

Engine

Displacement249.0 ccm (15.19 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke77.0 x 53.6 mm (3.0 x 2.1 inches)
Valves/Cylinder4
FuelingInjection. Delphi fuel injection system 34mm
Ignition
Exhaust
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final Drive
ClutchOil bath, multidisc
Driveline

Performance

Horespower27.5 HP (20.1 kW) @ 8000 RPM
Torque23.0 Nm (2.3 kgf-m or 17.0 ft.lbs) @ 7000 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.50 litres (1.98 US gallons)
Emissions

Chassis

Frame TypeComposite - aluminum/steel
Rake
Trail
Front SuspensionZF Sats 48 mm, adjustable
Front Travel280 mm (11.0 inches)
Rear SuspensionZF Sachs, multi adjustable
Rear Travel300 mm (11.8 inches)
Seat
Seat Height940 mm (37.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance340 mm (13.4 inches)
Wheelbase1465 mm (57.7 inches)
Dry Weight
Wet Weight118.0 kg (260.1 pounds)

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre120/90-18
Front BrakesSingle disc. 2-piston
Front Brake Diameter270 mm (10.6 inches)
Rear BrakesSingle disc. Single-piston
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the AJP PR5 250 Extrem. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 249.0 ccm (15.19 cubic inches) of actual displacement before compression. Fueling is metered via Injection. Delphi fuel injection system 34mm allowing this machine to produce its 27.5 HP (20.1 kW) @ 8000 RPM horsepower and 23.0 Nm (2.3 kgf-m or 17.0 ft.lbs) @ 7000 RPM torque. According to our records engine heat of the AJP PR5 250 Extrem is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 120/90-18 . The entire package is supported by the frame, Composite - aluminum/steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. 2-piston front brakes and Single disc. Single-piston rear brakes. The AJP PR5 250 Extrem was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

AJP is a Portuguese brand.
